GANDY

AUTOMATED ENDOSCOPE REPROCESSOR

A complete line of innovative products to ensure maximum safety and efficiency in the reprocessing of endoscopes.

ISO-NERO
Legislation

Designed and built in compliance with UNI stan-dards EN ISO 15883 – 1/-4/-5 UNIEN IS 14937: 2009; guarantee high disinfection level and / or low temperature sterilization flexible level and / or low temperature sterilization flexible endoscopes of all major manufacturers on the market.

HANDSFREE-NERO
"Hands Free" System

Composed of upper glass door tempered and an-ti-crush safety, ad automatic opening by button or pedal, facilitates the
activities of the operators and guarantees safety and convenience of use.

DISINFETTANTE-NERO
Single shot

Equipped with a closed-loop washing system, with use of detergent and disinfectant in single dose chemical solutions at each cycle, with con- centrations and exposure times that they comply with the guidelines; the canisters are placed in a
special Cabinet equipped with lock for controlled access.

FILTRO-NERO
Filtration system

The Endoscopes Washers of the Gandy series are equipped with a filtration system for water pro-duction microbiologically controlled which provi-des the use of two filters up to 0.1 microns and a for air that provides an activated carbon filter and one for removing acid vapors disinfectant.

VELOCITA-NERA
Fast and secure

Every single unit is optimized to ensure themes reduced treatment, ensuring a clean carried out to preserve with extreme care the integrity of your endoscopes with a time of reprocessing less than 23 minutes (standard cycle)..

VAPORE-NERO
Watertight seal

Watertight washing chamber, without emission of vapors into the environment, thanks to the activated carbon, controlled openings and non return.

Equipped with 2 asynchronous washing tanks, it allows reprocessing, by immersion and jet, 1 or 2 flexible endoscopes from the main manufacturers on the market through a disinfection / sterilization process.

Equipped with a single washing tank, it allows to reprocess, by immersion and jet, 1 flexible endoscope and up 4 Endoscopes without operative channels.

Gandy AER – 45 PT, equipped with a single wash tank, enables the reprocessing by immersion and jet of 1 flexible endoscope and up 3 ENT during high disinfection / sterilisation process.

IMPROVE HEALTH CARE PROTECTION FOR OPERATOR

Automatic door with  foot pedal switch – Automatic adding of chemical additives -Automatic disinfectants sampling function

CONSUMPTION CONTAINED:

• Spray and immersion washing mode,
consumption of the entire single cycle: 46 Lt.

• Detergent: 40 ml / cycle.

• Disinfectant: 70 ml / cycle.

RINSE WITH STERILE WATER:

After disinfection, rinsing with sterile water is
carried out, which is useful to avoid secondary
pollution phenomena.

DRYING PHASE:

Drying phase performed with steril air which is
filterd with 0.01 μm pores size filters.

EASY TO USE:
9.7 “display with touch screen, displays all rinsing phases in real time.

Fast and safe, it allows you to reprocess the endoscope with cycle times of only 19 minutes, while still ensuring perfect cleaning and integrity of the instrument

Metal jar with handles for flexible endoscope
